PowerLab Owner’s Guide
iii
Contents
Contents
iii
Safety Notes
v
1 Overview
1
How to Use this Guide 2
First, Check Your PowerLab! 2
The PowerLab System 3
Computer Requirements 3
The Application Programs 4
Other ADInstruments Hardware 4
The PowerLab 4
The Front Panel 5
The Back Panel 8
2 Setting Up
11
Self-Test 12
The USB Connection 13
Connecting the PowerLab Using USB 14
USB Connection Rules 15
A Technical Aspects
17
How Does it Work? 17
The Analog Inputs 20
PowerLab Accuracy 22
The External Trigger 22
The Analog Output 24
Connections 24
USB Port 24
I
2
C Expansion Port 25
Pod Connectors 25
Serial Port 26
B Troubleshooting
27
Problems: Macintosh 27
Problems: Windows 29
C Specifications
33
PowerLab 2/20 Specifications 33
PowerLab 4/20 Specifications 36
Glossary
39
Index
43
Licensing & Warranty Agreement
45
