ADJ ELEMENT HEX - Page 17

17
DMX TRAITS
CHANNEL
DMX
VALUES
FUNCTION
6CH 7CH 8CH 11CH 12CH
10 10
Sound Active Mode (continued)
192 - 207 Sound Active Mode 13
208 - 223 Sound Active Mode 14
224 - 239 Sound Active Mode 15
240 - 255 Sound Active Mode 16
11 11
000 - 255
Program Speed, slow to fast
000 - 255
Sound Sensitivity, least to most sensitive
12
Dimmer Curves
000 - 020 Standard
021 - 040 Stage
041 - 060 TV
061 - 080 Architectural
081 - 100 Theatre
101 - 255 Default to unit setting
NOTE ON 11 CHANNEL DMX MODE & 12 CHANNEL DMX MODE:
• When Channel 9 is between the values of 0-51, Channels 1-6 are used, and Channel 8 will con-
trol strobing.
• When Channel 9 is between the values of 52-102, Channel 10 is in Color Macros Mode, and
Channel 8 will control strobing.
• When Channel 9 is between the values of 103-153, Channel 10 is in Color Change Mode, and
Channel 11 will control the color change speed.
• When Channel 9 is between the values of 154-204, Channel 10 is in Color Fade Mode, and Chan-
nel 11 will control the color fade speed.
• When Channel 9 is between the values of 205-255, Channel 10 is in Sound Active Mode, and
Channel 11 will control the sound sensitivity.
