ADJ ELEMENT HEX - System Menu

19
SYSTEM MENU
MENU SUBMENU OPTIONS FUNCTIONS
DMX MODE
Address
d001~d512 DMX Address Setting
Channels
Ch06 6 DMX Channel Mode
Ch07 7 DMX Channel Mode
Ch08 8 DMX Channel Mode
Ch11 11 DMX Channel Mode
Ch12 12 DMX Channel Mode
No DMX mode
blAc When the DMX signal is lost or interrupted, the unit will go into BLACKOUT mode.
LASt When the DMX signal is lost or interrupted, the unit will hold at the LAST DMX setting.
ProG When the DMX signal is lost or interrupted, the unit will run an auto program.
Delay mode
dr-0~dr-4 Select the unit delay mode
SECONDARY
Secondary Setting
SEcd Designate the unit as a secondary unit in a primary-secondary set up.
DIMMER MODE
Red Dimmer r.000~r.255 Adjust the intensity of the red color.
Green Dimmer G.000~6.255 Adjust the intensity of the green color.
Blue Dimmer b.000~6.255 Adjust the intensity of the blue color.
White Dimmer U.000~U.255 Adjust the intensity of the white color.
Amber Dimmer A.000~A.255 Adjust the intensity of the amber color.
UV Dimmer u.000~u.255 Adjust the intensity of the UV color.
Flash Adjustment f5.00~5o 1G Adjust the ash speed. “00” is O, “01” is the slowest speed, and “15” is the fastest.
SOUND MODE
Sound Active so01~so1G Select 1 of 16 sound active programs.
Sensitivity Adjust sj-0~sj-8 Adjust the sound sensitivity. “0” is the lowest level, and “8” is the highest level.
AUTO RUN MODE
Color Fade Mode
AF01~AF16 Select 1 of 16 color fade modes.
Color Change Mode
AJ01~AJ16 Select 1 of 16 color change modes.
Color Change &
Color Fade Mode
A-JF This mode will run both color change and color fade continuously.
Speed Adjustment
SP.01~SP.16 Adjust the running speed of the current mode.
STATIC COLOR
MODE
Color Select
CL00~CLG3 Select 1 of 63 static colors.
Flash Adjustment
f5.00~f5.15 Adjust the ash speed. “00” is O, “01” is the slowest speed, and “15” is the fastest.
BATTERY LIFE
ENERGY SAVE
LOADING
SET UP
Battery Life Display
6---/
6000~b100
Displays the current battery life.“b---” means that the battery is not being
used.“bXXX” means that the battery is in use. “XXX” represents the battery charge
percentage.“b000” means that the battery has no charge.“b100” means that the battery
is at full charge.
Energy Saving
Mode
65on Activates energy saving mode.
b5oF Deactivates energy saving mode.
Load On/O Select
Loon Activates battery power.
LooF Deactivates battery power.
OTHER
Display
don LED display is always on.
dooF LED display turns o after 30 seconds.
IR Remote On/O
iron IR remote function is activated.
iroF IR remote function is deactivated.
Display
Normal/Inverted
stnd LED digital display is normal.
-3- LED digital display is inverted.
Menu Lock
loC1 Deactivate display lock. (Display lock is not active)
LoC2 Activate display lock. (Press the MODE button for 3 seconds to unlock the display)
LoC3 Activate display lock two.(Press UP-DOWN-UP-DOWN to unlock the display)
Initialization Mode
dEFA Default to factory settings.
WIFLY SET UP
WiFly Address rC00~rC14 Set the WiFly address.
WiFly Function
On/O
rCon WiFly function is active
rCof WiFly function is not active.
