ADJ Products, LLC - www.adj.com - Focus Spot 4Z User Manual Page 8
Focus Spot 4Z Installation
Screw one clamp each via a M12 screw and nut into the Omega bracket. Insert the quick-lock fasteners of
the Omega holder’s into the respective holes on the bottom of the Focus Spot 4Z. Tighten the quick-
lock fasteners fully clockwise. Pull the safety cable through the openings located on the base plate
and over the trussing system or a safe xation spot. Insert the end in the carabine and tighten the
safety screw.
NOTICE: The suitable enviromental temperature for this lighting xture is between -25˚ C to 45˚ C.
Do not place this lighting xture in an enviroment where the temperatures are under or above the
temperatures stated above. This will allow the xture to run at its best and help prolong the xture
life.
SAFETY CABLE
