ADJ Focus Spot Two - DMX Control Functions (16 Channel Mode); Pan, Tilt, and Color Channels; Gobo, Rotation, and Prism Channels; Dimmer and UV Strobe Channels

ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 12 ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 13
Focus Spot Two 16 Channel Mode
Channel Value Function
1 0 - 255 PAN MOVEMENT 0° - 540
2 0 - 255 TILT MOVEMENT 0° - 230°
3 COLOR
0 - 14 WHITE
15 - 29 RED
30 - 44 BLUE
45 - 59 GREEN
60 - 74 YELLOW
75 - 89 PINK
90 - 104 LIGHT BLUE
105 - 119 LIGHT GREEN
120 - 127 LIGHT YELLOW
128 - 189 CLOCKWISE ROTATION FAST - SLOW
190 - 193 STOP
194 - 255 COUNTER-CLOCKWISE ROTATION
SLOW - FAST
4 GOBOS
0 - 9 OPEN
10 - 18 GOBO 1
19 - 27 GOBO 2
28 - 36 GOBO 3
37 - 45 GOBO 4
46 - 55 GOBO 5
56 - 63 GOBO 6
64 - 73 OPEN SHAKE
74 - 82 GOBO 1 SHAKE
83 - 91 GOBO 2 SHAKE
92 - 100 GOBO 3 SHAKE
101 - 110 GOBO 4 SHAKE
111 - 119 GOBO 5 SHAKE
120 - 127 GOBO 6 SHAKE
128 - 189 CLOCKWISE ROTATION FAST - SLOW
190 - 193 STOP
194 - 255 COUNTER-CLOCKWISE ROTATION
SLOW - FAST
Focus Spot Two 16 Channel Mode
Channel Value Function
5 GOBO ROTATION
0 - 127 INDEXING
128 - 189 CLOCKWISE ROTATION FAST - SLOW
190 - 193 STOP
194 - 255 COUNTER-CLOCKWISE ROTATION
SLOW - FAST
6 PRISM
0 - 7 NO EFFECT
8 - 255 PRISM EFFECT
7 STROBE/SHUTTER
0 - 7 OFF
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 RANDOM STROBE SLOW - FAST
248 - 255 OPEN
8 0 - 255 MASTER DIMMER 0% - 100%
9 UV STROBE/SHUTTER
0 - 7 OFF
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 RANDOM STROBE SLOW - FAST
248 - 255 OPEN
10 0 - 255 UV MASTER DIMMER 0% - 100%
11 0 - 255 FOCUS 0%- 100%
