ADJ MEGA FLAT PAK 8 PLUS - 9 Channel Mode

ADJ Products, LLC - www.adj.com - Mega Flat Pak 8 Plus User Manual Page 18 ADJ Products, LLC - www.adj.com - Mega Flat Pak 8 Plus User Manual Page 19
Channel Value Function
8 COLOR MACROS/PROGRAMS/
SOUND ACTIVITIY
COLOR CHANGE PROGRAMS
48 - 63 COLOR CHANGE 4
64 - 79 COLOR CHANGE 5
80 - 95 COLOR CHANGE 6
96 - 111 COLOR CHANGE 7
112 - 127 COLOR CHANGE 8
128 - 143 COLOR CHANGE 9
144 - 159 COLOR CHANGE 10
160 - 175 COLOR CHANGE 11
176 - 191 COLOR CHANGE 12
192 - 207 COLOR CHANGE 13
208 - 223 COLOR CHANGE 14
224 - 239 COLOR CHANGE 15
240 - 255 COLOR CHANGE 16
COLOR FADE PROGRAMS
0 - 15 COLOR FADE 1
16 - 31 COLOR FADE 2
32 - 47 COLOR FADE 3
48 - 63 COLOR FADE 4
64 - 79 COLOR FADE 5
80 - 95 COLOR FADE 6
96 - 111 COLOR FADE 7
112 - 127 COLOR FADE 8
128 - 143 COLOR FADE 9
144 - 159 COLOR FADE 10
160 - 175 COLOR FADE 11
176 - 191 COLOR FADE 12
192 - 207 COLOR FADE 13
208 - 223 COLOR FADE 14
224 - 239 COLOR FADE 15
240 - 255 COLOR FADE 16
Mega Flat Pak 8 Plus
9 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 UV
0 - 255 0% - 100%
5 SHUTTER/STROBE
0 - 31 LED OFF
32 - 63 LED ON
64 - 95 STROBING SLOW - FAST
96 - 127 LED ON
128 - 159 STROBE PULSE SLOW - FAST
160 - 191 LED ON
192 - 223 RANDOM STROBE SLOW - FAST
224 - 255 LED ON
6 MASTER DIMMER
0 - 255 0% - 100%
7 PROGRAM SELECTION MODE
0 - 51 DIMMING MODE
52 - 102 COLOR MACRO MODE
103 - 153 COLOR CHANGE MODE
154 - 204 COLOR FADE MODE
205 - 255 SOUND ACTIVE MODE
8 COLOR MACROS/PROGRAMS/
SOUND ACTIVITY
0 - 255 COLOR MACRO MODE
(See page 24 for the Color Macro Chart)
COLOR CHANGE PROGRAMS
0 - 15 COLOR CHANGE 1
16 - 31 COLOR CHANGE 2
32 - 47 COLOR CHANGE 3
Mega Flat Pak 8 Plus
9 Channel Mode
