Adkins Beta Swift - Controller Electrical Diagram

5.5 Controller Electrical Diagram
DI1 GND DI2 GND RT+ RT-
J4 AC L
Heat Sink
XS1
XS2
XS1
XS2
To Controller Facia
J3 1. Jumper 'ON' for Manual Press 2. Jumper 'OFF' for Auto Press
J7 AC N J6 J5
N
To
Element
1. Connect to 'Push Button 1' if installing in an 'Automatic Press' 2. Connect to 'Microswitch' if installing in a 'Manual Press'
To Mains Earth Stud
'Ribbon Cable'
Sockets
Buzzer
+
Green
(Probe)
-
White
L
N
from Mains
(via Switch)
L
J8 J9 J10
AIR PGND
MAIN BOARD
POWER BOARD
J2 1. Jumper 'ON' for Centigrade 2. Jumper 'OFF' for Farenheight
J1
Page 16
