3



#6LOOSEELECTRICALCONNECTIONS—Damagetoequipmentcanoccurifthefollowingprecautionsarenot

observed.Beforeconnectingpowertothemachine,checkallelectricalterminalsinthecontrolbox.Screws

canloosenintransit.Looseconnectionsonhighamploadterminalssuchasthepumpmotorwillcause

wireburningand

componentdamageduringoperationandwillnotbecoveredunderADSwarranty.

#7“CLEANCIRCUIT”meanstheelectricalcircuitbreakerforthedishmachinesuppliesnootheroutlets,

machines,orlights.GFCIoutletsarenotrecommendedforcommercialdishmachines;ADSrecommends

thatasingle‐rackmachinebeinstalledwiththewireconnection(hard‐wired)directlyfromthecircuit

breaker.Ifaplugandsocketareusedtoprovideelectricalpowertoadishmachineinacommercialkitchen,

thenaccordingtoelectricalcodeitmustbeaGFCI,butnotallGFCIsarethesame.Theymustberatedfor

thedrawofthecircuit.

ReferenceNECArticle210.8GFCIProtection(B)OtherThanDwellingUnits(2)CommercialandInstitutional

Kitchens.All15and20A,125Vreceptaclesinstalledinkitchens,eventhosethatdonotsupplythecountertop

surface,mustbeGFCIprotected.

Thisequipmentisconsideredanitemofheavyuse.Itisnotratedforoutdooruse.

ELECTRICALSECTION

Theelectricalpowersuppliedtothismachineisanimminenthazardthatcouldresultinseverebodily

injuryordeathifnotproperlyinstalledorhookedupcorrectly

Electrical—ET‐AF‐M,ET‐AF‐3w/PumpDrain,SustainerHeater(120volt,20amp) 

Atimecycleof90‐secondsistheshortesttimeavailableforthismodelandiscompliantwithNSFlisting.To

changetoalongertimecycle,theentirecamtimerassemblymustbechangedbecauseofthemotorgearing. 

 

Showingcontrolsonloweraccessdoor&drainpumpControlboxwithcoverremoved

Thepowersupplyfor120volts,20amps,shallconsist oftwo#10‐12‐gaugewiresandonesuitablegreen

groundwire.The20ampbreakeror20ampfusemustbeonacleancircuitforonlythismachine.ADShas

providedajunctionboxwitha7/8”holeforthe1/2”conduitthatwillbringthebuilding’selectricalpowerto
