HD/SD-SDI Input 2
BNC 75 Ohm Input
CVBS Composite Input 2
BNC 75 Ohm Input
Analog Audio Input 2
DB9
EAS Video In
RCA 75 Ohm
EAS Video Loop Out
RCA 75 Ohm
EAS Audio In
Vertical single RCA jack
EAS Audio Loop Out
Vertical single RCA jack
ASI Input
BNC 75 Ohm
Output
Connection
Function
ASI Out
BNC 75 Ohm, Asynchronous Serial Interface (EN 50083-9)
RF L-band
BNC 75 Ohm, L-Band out
RF IF
BNC 75 Ohm, IF out
RF Monitor
BNC 75 Ohm, Fixed power -45dBm. IF mode frequency 1080MHz.
L-Band mode tracks frequency of output.
10 MHz Clock
BNC 75 Ohm
