ADT-TP3340DJ Three-axis Dispenser

- 24 -

Chapter III. Hardware Connection

External 12-24V current

Common input end

X-axis origin

Y-axis origin

Z-axis origin

U-axis origin

Stop button

Gun opening/closing button

Start station 1

Start station 2

X-axis forward limit

X-axis reverse limit

Y-axis forward limit

Y-axis reverse limit

Z-axis forward limit

Z-axis reverse limit

U-axis forward limit

U-axis reverse limit

X-axis: Left/right movement

Z-axis: Up/down movement of glue gun

Y-axis: Front/back movement of station 1

U-axis: Front/back movement of station 2

Customer General Item No.

Item name TP3340 dispenser

Graph name 37-core input board wiring diagram Page 1/3

Drawn by Tang Gongyi Date 09/9/29 Version C

Adtech (Shenzhen) CNC Technology Co., Ltd.

37-core si

nal socket

Motor Motor Motor Motor

Common input end

External 12-24V DC power supply
