Specifications & Ordering:
Sales Order Parts:
Options:
Mx-4010: (RDT) Remote Display Terminal
Mx-4020: (RCT) Remote Control Terminal
Mx-4010/FT: (RDT) with Fault Tolerant Network I/F
Mx-4020/FT: (RCT) with Fault Tolerant Network I/F
Mxm-008: Semi Flush Bezel
Mxp-018: Access Enable Key-Switch
Item
Specification Details
Display
Backlit 240 x 64 graphical LCD
LED Indicators
3 Red (2 x Fire, 1 x Alarm), 1 Green (Power) & 7 Amber (Fault & System)
Keypad
Alpha Numeric Keypad, Navigation Keys & on-board buzzer mute facility
Controls ( only)
System Keys for Reset, Silence, Resound & Evacuate
Key-Switch Input
Optional Level 2 Access Enable key switch
Power Supply Input
24 VDC, 150mA (/FT: 188mA) Operating range 15-30V
External Supply Monitoring
Monitored External Fault Input
Number of Fire Zones
1000
Serial port
1 RS232 Onboard for PC connection
Programming
Via on-board Keypad or PC running Windows Tools
Enclosure
Steel IP30
Cable Entry
20mm Knock-outs. 4 x top and 4 x rear
Colour
Beige (textured)
Size H x W x D mm
Enclosure: 218 x 300 x 44
Back Box only (when recessing): 218 x 300 x 30
Weight
2Kg
Metalwork Options
Semi Flushing Bezel, Special Finishes including Brass & Chrome
As our policy is one of constant product improvement the right is therefore reserved to modify product specifications without prior notice
