Advantech AIM 10W - Top and Bottom View Connectors

21

1.5.5AIM10TopView




No. Component
1 Power Button
2 Volume Button( Up, Down)
3 Barcode Scanner
4 Programmable Button
1.5.6  AIM10BottomView





No. Component
1 RF Pass Through Connector
2 16 pin pogo connector
3 Positioning hole
4 SIM Card/ Micro-SD Card cover



43
1 2
1
3
4
2
