S
tart Guide
First Use
Before applying power to the router, connect the components that you required for your
applications. You cannot operate the router without connected antenna, inserted SIM card,
nor connected power supply.
If
you do not have connected main antenna during operation of the router, the router can
be damaged!
1.
Antenna
Use a SMA connector to connect the antennas to the router. The main antenna is con-
nected to the router by screwing on the ANT connector (see Figure below). The second diver-
sity antenna can also be connected to the DIV connector to improve performance.
2.
SIM Card
The SIM card reader, for 3 V and 1.8 V SIM cards, is located on the front panel of the
router. If you intend to use this device to communicate over a cellular network, please place
an activated data-provisioned SIM card with an unblocked PIN into the SIM card reader. Push
your SIM card into the SIM1 or SIM2 slot until it clicks in place.
QSG-0005-EN, October 9, 2018 3 Released in the Czech Republic
