Advent AW810 User Manual

3
Q
N
M
A. Tuning Indicator Light
B. Tuning Control Knob
C. Power ON-OFF/Volume Control Knob
D. Speaker Power Input Jack
E. Battery Compartment Cover
F. Audio Level Indicator Light
G. Output Level Control Wheel
H. Right Audio Input Jack
I. Left Audio Input Jack
J. Frequency Control Wheel
K. Charge Output Jack – for use with
Advent AW770 and AW720 Wireless
Headphones only
L. Transmitter Power Input Jack
M. Transmitter AC Adapter – 18V DC
N. Speaker AC Adapter (x1) – 12V DC 500 mA
O. Dual RCA Cable
P. “Y” Cable Adapter
Q. Headphone Adapter Plug
OPEN OPEN
BA
CD
E
F
OUTPUT LEVEL
AUDIO IN
LR
TUNING
CHARGE
DC 18V
KG H I
J
L
P
O

Advent AW810 Specifications

General

Brand	Advent
Model	AW810
Category	Speakers
Language	English
