5
Note: If you select Option 1 or Option 2 to connect the transmitter, the audio level will
be fixed or variable, depending on your equipment. If you select Option 3, the audio level
will be variable.
POWER THE SPEAKER
Select from the following options
to power the AW810 speaker:
POWER OPTION 1 – “C” CELL BATTERIES
1. Turn the speaker Power ON-OFF/
Volume Control Knob (C) to the “OFF”
position (all the way counter-
clockwise – it will “click” off).
2. Remove the Battery
Compartment Cover (E).
3. Insert eight (8) “C” batteries
(not included) into the speaker
following the polarity (“+” and “–”)
as diagrammed in the battery
compartment.
4. Replace the Battery Compartment Cover.
POWER OPTION 2 – AC ADAPTER
1. Turn the speaker Power ON-OFF/Volume
Control Knob (C) to the “OFF” position (all the
way counterclockwise – it will “click” off).
2. Insert the power cord from the Speaker AC
Adapter (N) into the Speaker Power Input
Jack (D).
3. Plug the Speaker AC Adapter (N)
into any standard wall outlet.
Note: Be sure to use the AC
Adapter rated 12V DC 500 mA.
Speaker AC
Adapter (N)
