English
G B
2/4 4/4
3/4 4/4
1. Make sure the switch is connected and the key is positioned on OFF.
2. Keep the button on the switch pressed down.
3. Turn the ignition key to ON and start the vehicle.
4. Two-colour LED (Red/Green) blinking.
5. Keep the button pressed down until the LED blinks Red only
6. Release the button; the LED now blinks Green.
TYPE OF LEVEL SENSOR PROGRAMMING:
1. Press the button several times until you get the desired level sen-
sor programming.
YELLOW LED ON:• A.E.B. sensor
1/4 GREEN LED ON:• 0÷4700 Ohm sensor
2/4 GREEN LED ON: • 0÷90 Ohm sensor
3/4 GREEN LED ON: • RESERVE sensor
2. Keep the button pressed for 3 seconds in order to save and go on
to the next setting.
Programming
G 4/4
4/4 o B
RESERVOIR FILLING AND EMPTYING PROGRAMMING
1. Two-colour LED with GREEN on.
2. Press the button until you get the desired programming.
2/4 GREEN LED ON: • Switch with RESERVOIR EMPTYING only
3/4 GREEN LED ON: • Switch with RESERVOIR FILLING AND
EMPTYING
3. Keep the button pressed for 3 seconds in order to save and go on
to the next setting.
PRIMING TIME PROGRAMMING
1. Two-colour LED with RED on
2. Press the button until you get the desired programming.
YELLOW LED OFF: • Priming time null.
YELLOW LED BLINKING: • Priming time enabled.
3. Press the button quickly 2 times to increase the priming time up
to the desired value.
4. Keep the button pressed for 3 seconds until the two-colour LED
blinks RED/GREEN.
5. Turn the ignition key to OFF.
NOTE: The steps listed above must be followed in sequence in
order to complete programming correctly.
G B
4/4 o B
