AEG AGB728E4NX - Dimensions

EN - 12 -
Dimensions
3
the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air, plus
the space necessary to allow
door opening to the minimum
angle permitting removal of all
internal equipment
Overall dimensions
1
H1* mm 1860
W1 mm 595
D1 mm 650
Space required in use
2
H2 mm 1900
W2 mm 600
D2 mm 718
1
the height, width and depth of the
appliance without the handle
* including the height of the top
hinge (10 mm)
2
the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air
Overall space required in use
3
W3 mm 649
D3 mm 1224
H1
H2
W1
D1
W2
D2
W3
D3
90
o
