3.6 Reversing the freezer
compartment door
WARNING!
Before carrying out any operations,
remove the plug from the power socket.
1. Close the freezer compartment door.
Unscrew the screw of the installation
button. Place the installation button and
the screw in a safe place.
2. Open a freezer compartment door
slightly. Pull down the freezer
compartment door and the cap from the
door upper bearing.
3. Remove the installation buckle and install
it on the opposite side.
4. Reverse the freezer compartment door by
180 degrees. Install the cap on the door
upper bearing.
5. Fit the freezer compartment door and
close them.
6. Fix the installation button to the door
lower bearing. Press the installation
button until there is no gap between it and
cavity, then fix the screw.
7. Take out hole covers from a bag and put
them in the holes left after the door hinge.
74 ENGLISH
