WARNING!
The power cable must not
touch the part of the
appliance shaded in the
illustration.
13.5 Covering terminal board
• The recommended cross-section area
is six square millimetres (6 mm²).
• When you refit the mains terminal
cover, make sure that the lower tabs
are located inside the bottom edge of
the aperture, before you fix the two
screws into the top edge of the mains
terminal cover.
• Make sure that the cover is securely
fastened.
To open the cover of
terminal board obey the
procedure in opposite
sequence.
13.6 Terminal board
Do not remove blanking
plates.
Make sure that the links are fitted as
shown.
N N N
LL
14. ENERGY EFFICIENCY
14.1 Product information for hob according to EU 66/2014
Model identification CCB6761ACB
CCB6761ACM
Type of hob Hob inside Freestanding Cooker
Number of cooking zones 4
Heating technology Radiant Heater
Diameter of circular cooking
zones (Ø)
Left front
Left rear
Right front
Right rear
14.0 cm / 21.0 cm
14.5 cm
14.5 cm
18.0 cm
Energy consumption per
cooking zone (EC electric
cooking)
Left front
Left rear
Right front
Right rear
178.9 Wh/kg
181.8 Wh/kg
181.8 Wh/kg
192.3 Wh/kg
Energy consumption of the hob (EC electric hob) 183.7 Wh/kg
