1 Figure captions
1.1 Front view (Fig. 1)
A Drip grid
B Thermos jug
C Main switch (rear side of appliance)
D Height-adjustable coffee dispenser
E Control panel (see Fig. 3)
F Bean container lid
G Pre-ground coffee lid
H Heated cup rack
J Swivel pipe for steam and hot water
K Steam nozzle (removable)
L Inner part of steam nozzle (removable)
M Service door opening button
N Water tank with max. fill level indica-
tion (removable)
O Drip tray with float (removable)
1.2 Front view with open service
door (Fig. 2)
P Service door (open)
Q Waste coffee container (removable)
R Tilt compartment
S Brewing unit
T Knob for setting grinding texture
U Bean container
V Measuring spoon
W Funnel for pre-ground coffee
X Type plate (under appliance)
Y Liquid descaler
Z Test strip for water hardness
1.3 Control panel (Fig. 3)
a "Coffee strength / Pre-ground coffee"
knob
b "Cup size" knob
c Display
d "1 cup of coffee" key
In Menu mode, use this key for
"scrolling" ("<")
e "2 cups of coffee" key
In Menu mode, use this key for
"scrolling" (">")
f "Steam" key
In Menu mode, use this key to confirm
a menu item ("OK")
g "MENU“ key
In Menu mode, this key returns to the
last level without changing settings
("ESC")
h "ON/OFF“ key
j Knob for "Steam / Hot water“
k "Jug coffee function“ key
