1 Figure captions
3
This manual is valid for the Fully Auto-
matic Espresso Maker version CS 5000
and version CS 5200. The operation of
both models is similar.
Figure 1 and figure 2 show both ver-
sions. All other illustrations show ver-
sion CS 5200.
1.1 Front view (Fig. 1)
A Cup warmer tray
B Steam knob
C Steam spout
D Milk frother
E Milk frother (removable)
F Milk frother nozzle (removable)
G Service door opening button
H Water tank (removable)
J Drip tray (removable)
K Cup support tray
L Coffee spout, adjustable in height
M Control panel (see Fig. 3)
N Bean container lid
O Centre lid for the ground coffee
1.2 Front view with open service
door (Fig. 2)
P Measure for pre-ground coffee
Q Compartment for the measure
R Funnel for pre-ground coffee
S Service door
T Removable container for the coffee
grounds
U Mobile drawer
V Infuser
W Grinding coarseness adjustment knob
X Container for the coffee beans
Y Type plate (under appliance)
Z Liquid descaler and
Test strip for water hardness
1.3 Control panel (Fig. 3)
a Coffee quantity selector knob (short,
normal or long)
b Grinding quantity selector knob (for
weak, normal or strong coffee)
c One cup button
d Two cup button
e On/off button
f Steam function selector button
g Ground coffee button (disables the
coffee grinder)
h Rinse and descaling button
j 1 cup and coffee temperature OK light
k 2 cup and coffee temperature OK light
l Steam and steam temperature OK light
m Ground coffee light (coffee grinder
disabled)
n Scale alarm light
o No water or water tank absent
indicator light
p Grounds container full or absent
indicator light
q Generic alarm indicator light
