AEG GS 500 E - Page 3

4 5
A...........G
START
STOP
3
2
1
2
1
a (mm) b (mm) c (mm) d (mm) s (mm)
13 25 40 6 max. 25
40 40 6 max. 25
16 25 40 6 max. 25
32 40 6 max. 25
40 40 6 max. 25
50 40 6 max. 25
20 10 40 6 max. 25
20 40 6 max. 25
25 40 6 max. 25
32 40 6 max. 20
25 10 40 6 max. 25
16 40 6 max. 25
20 40 6 max. 25
25 40 6 max. 25
a
b c
s
d
d
D
d = D !
