3.8 Assembly
1.
2.
3.
40-50 mm
55 mm
30 mm
min. 650 mm
490 mm
340 mm
min. 100 mm
4.
5.
6.
B
A
A) supplied seal
B) assembled bracket
7.
CAUTION!
Install the appliance only on
a worktop with flat surface.
3.9 Installation of more than
one hob
Supplied accessories: connection bar,
sealing stripe.
Use only a special heat-
resistant silicone.
