4. PRODUCT DESCRIPTION
4.1 Cooking surface layout
120/175/210
mm
120/175/210
mm
145 mm
170 mm
265 mm
170 mm
265 mm
145 mm
11
1 1
2
1
Cooking zone
2
Control panel
4.2 Control panel layout
1 2 4
5
7
9 8
6
3
Use the sensor fields to operate the appliance. The displays, indicators and sounds
tell which functions operate.
Sen‐
sor
field
Function Comment
1
- To activate and deactivate the outer ring.
2
- Heat setting display To show the heat setting.
3
- Timer indicators of cooking
zones
To show for which zone you set the time.
4
- Timer display To show the time in minutes.
5
- To select the cooking zone.
