10. TECHNICAL DATA
10.1 Rating plate
Model IKK86683FB PNC 949 597 793 00
Typ 62 D6A 06 AD 220 - 240 V / 400 V 2N 50 - 60 Hz
Induction 7.2 kW Made in Germany
Ser.Nr. ................. 7.2 kW
AEG
10.2 Cooking zones specification
Induction cooking
surface
Nominal power
(maximum heat
setting) [W]
PowerBoost [W] PowerBoost maxi‐
mum duration [min]
Single triangle 1150 1600 10
Standard cooking
zone
2000 3000 10
Centre zone 4200 - -
Vertical zone 3200 - -
Horizontal left zone 4100 - -
Horizontal right zone 3200 - -
The power of the cooking zones can be different from the data in the table. It changes
with the material and dimensions of the cookware.
Cookware sizes
Bridge mode Cookware dimension (min‐
imum)
Cookware dimension
(maximum)
Single triangle 100 mm 160 mm
Standard cooking zone 160 mm 210 mm
Centre zone 240 mm 350 mm
Vertical zone The area of 3 single trian‐
gles
The area of 4 single trian‐
gles
Horizontal zone The area of 3 single trian‐
gles
The area of 4 single trian‐
gles
For more information on the recommended cookware dimensions, refer to "Induction
cooking surface" in "Daily use".
