3.4 Assembly
If you install the hob under a hood,
please see the installation instructions of
the hood for the minimum distance
between the appliances.
min.
50mm
min.
500mm
65 ± 1mm
490± 1mm
55± 1mm
If the appliance is installed above a
drawer, the hob ventilation can warm up
the items stored in the drawer during the
cooking process.
Find the video tutorial "How to install
your AEG Induction Hob - Worktop
installation" by typing out the full name
indicated in the graphic below.
www.youtube.com/electrolux
www.youtube.com/aeg
How to install your AEG
Induction Hob - Worktop installation
www.aeg.com8
