Setting up and connection instructions
50
Water Inflow
A pressure hose 1.5m in length is supplied.
If a longer inflow hose is required, only a VDE-approved, complete set
of hoses with fitted hose screw connections offered by our Customer
Service is permissible.
– Sets of hoses in lengths of 2.2m, 3.5m and 5m are available for
washing machines without Aqua-Control.
– Sets of hoses in lengths of 2.0m, 2.9m and 3.9m are available for
washing machines with Aqua-Control.
Attention! Never cut into pieces in order to extend the hoses!
3
Sealing rings are supplied either in the plastic
nuts of the hose screw connection or in the
enclosed pack. Do not use other seals!
0 1. Connect the hose with the angled connection to
the machine.
Attention!
– Do not lay the supply hose
vertically downwards. Rather,
turn it to the right or left as
shown in the diagram.
– Only tighten the screw
connection manually.
2. Connect the hose with the
straight connection to a water tap with a screw
thread of R 3/4 (inches).
Attention! Only tighten the screw connection
manually.
3. By slowly opening the water tap before putting
the washing machine into operation, check
whether the connection is free of leaks.
