AEG L6FBK841B User Manual

2
1
2. Remove the top part of the additive
compartment to aid cleaning. Make
sure that all detergent residue is
removed from the upper and lower
part of the recess. Use a small brush
to clean the recess.
3. Flush the detergent drawer out under
running warm water to remove any
traces of accumulated detergent.
After cleaning, replace the top part in
its position.
4. Insert the detergent drawer into the
guide rails and close it. Run the
rinsing programme without any
clothes in the drum.
14.9 Cleaning the drain pump
WARNING!
Disconnect the mains plug
from the mains socket.
Regularly check the drain
pump filter and make sure
that it is clean.
Clean the drain pump if:
• The appliance does not drain the
water.
• The drum does not turn.
• The appliance makes an unusual
noise because of the blockage of the
drain pump.
• The display shows the alarm code
.
WARNING!
• Do not remove the filter
while the appliance
operates.
• Do not clean the pump if
the water in the appliance
is hot. Wait until the water
cools down
Proceed as follows to clean the pump:
1. Open the pump cover.
ENGLISH 29

AEG L6FBK841B Specifications

General

Door hinge	Left
Water fill	Cold
Cord length	1.8 m
Control type	Buttons, Rotary
Display type	LED
Door opening	Side opening
Loading type	Front-load
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Country of origin	Poland
Inlet hose length	1.3 m
Illumination color	Red
Outlet hose length	1.45 m
Appliance placement	Freestanding
Self-cleaning	-
Drum capacity	8 kg
Maximum spin speed	1400 RPM
Noise level (wash)	75 dB
Number of washing programs	14
Current	13 A
Connected load	1900 W
AC input voltage	230 - 240 V
AC input frequency	50 Hz
Water consumption per cycle	43 L
Package depth	635 mm
Package width	640 mm
Package height	900 mm
Package weight	71000 g
Intrastat code	84501190

Weight and Dimensions

Depth	547 mm
Width	596 mm
Height	847 mm
Weight	69500 g
