AEG L7FBE49BSA User Manual

7. Remove the polystyrene protection
from the bottom.
1
2
8. Pull up the appliance in vertical
position.
9. Remove the power supply cable and
the drain hose from the hose holders.
It is possible to see
water flowing from the
drain hose. This is due
to the testing with water
of the appliance in
factory.
10. Remove the three bolts by using the
spanner supplied with the appliance.
11. Pull out the plastic spacers.
12. Put the plastic caps, that you find in
the user manual bag, in the holes.
We recommend that you
keep the packaging and the
transit bolts for any
movement of the appliance.
5.2 Positioning and levelling
1. Install the appliance on a flat hard
floor.
Make sure that carpets do
not stop the air circulation
below the appliance.
Make sure that the appliance
does not touch the wall or
other units.
2. Loosen or tighten the feet to adjust
the level.
www.aeg.com10

AEG L7FBE49BSA Specifications

General

Door type	Tempered glass
Door color	Silver
Door hinge	Left
Cord length	1.62 m
Drum volume	69 L
Control type	Buttons, Rotary
Door opening	Side opening
Loading type	Front-load
Product color	White
Illumination color	Red
Appliance placement	Freestanding
Dispenser tray type	4-way
Inverter technology	Yes
Drum capacity	9 kg
Cycle time (max)	220 min
Spin-drying class	B
Maximum spin speed	1351 RPM
Noise level (spin)	75 dB
Noise level (wash)	- dB
Load balancing system	-
Number of washing programs	11
Cycle time (quick washing program)	20 min
Current	10 A
Connected load	2200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	46 L
Energy consumption washing per cycle	0.493 kWh

Weight and Dimensions

Depth	631 mm
Width	597 mm
Height	847 mm
