AEG L7FBE49BSA User Manual

Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
8 bar (0.8 MPa)
Water supply
1)
Cold water
Maximum Load Cotton 9 kg
Spin Speed Maximum spin speed 1351 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
WARNING!
Remove all the packaging
and the transit bolts before
installing the appliance.
WARNING!
Use the gloves.
1. Remove the external film. If
necessary, use a cutter.
2. Remove the cardboard top and the
polystyrene packaging materials.
3. Remove the internal film.
4. Open the door and remove the
polystyrene piece from the door seal
and all the items from the drum.
5. Carefully put the appliance down on
its rear side.
6. Put the front polystyrene packaging
element on the floor under the
appliance.
Make sure not to
damage the hoses.
ENGLISH 9

AEG L7FBE49BSA Specifications

General

Door type	Tempered glass
Door color	Silver
Door hinge	Left
Cord length	1.62 m
Drum volume	69 L
Control type	Buttons, Rotary
Door opening	Side opening
Loading type	Front-load
Product color	White
Illumination color	Red
Appliance placement	Freestanding
Dispenser tray type	4-way
Inverter technology	Yes
Drum capacity	9 kg
Cycle time (max)	220 min
Spin-drying class	B
Maximum spin speed	1351 RPM
Noise level (spin)	75 dB
Noise level (wash)	- dB
Load balancing system	-
Number of washing programs	11
Cycle time (quick washing program)	20 min
Current	10 A
Connected load	2200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	46 L
Energy consumption washing per cycle	0.493 kWh

Weight and Dimensions

Depth	631 mm
Width	597 mm
Height	847 mm
