AEG L7FBE49BSA User Manual

3.2 Appliance overview
1 2 3
9
5
6
7
4
10
8
11 12
1
Worktop
2
Detergent dispenser with AutoDose
tanks and manual compartments
3
Control panel
4
Door handle
5
Rating plate
6
Drain pump filter
7
Feet for levelling the appliance
8
Drain hose
9
Inlet hose connection
10
Mains cable
11
Transit bolts
12
Hose support
00000000
00A
Mod.
xxxxxxxxx
000V ~ 00Hz 0000 W
910000000
00
A
B
C
Prod.No.
D
The rating plate reports the model name (A) ,
product number (B), electrical ratings (C) and
serial number (D).
4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /66.0 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
Level of protection against ingress of solid particles and
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against mois‐
ture
IPX4
www.aeg.com8

AEG L7FBE49BSA Specifications

General

Door type	Tempered glass
Door color	Silver
Door hinge	Left
Cord length	1.62 m
Drum volume	69 L
Control type	Buttons, Rotary
Door opening	Side opening
Loading type	Front-load
Product color	White
Illumination color	Red
Appliance placement	Freestanding
Dispenser tray type	4-way
Inverter technology	Yes
Drum capacity	9 kg
Cycle time (max)	220 min
Spin-drying class	B
Maximum spin speed	1351 RPM
Noise level (spin)	75 dB
Noise level (wash)	- dB
Load balancing system	-
Number of washing programs	11
Cycle time (quick washing program)	20 min
Current	10 A
Connected load	2200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	46 L
Energy consumption washing per cycle	0.493 kWh

Weight and Dimensions

Depth	631 mm
Width	597 mm
Height	847 mm
