5. CONTROL PANEL
5.1 Control panel description
1
12 9 8
101113
72 3 4 5 6
On/Off
Start/
Pause
Cottons
Synthetics
Delicates
Outdoor
Steam
Spin/Drain
Rinse
Anti-allergy
Duvet
20min 3kg
Sport
Denim
Wool/Silk
Cottons Eco
Temp.
Spin
Prewash Stains Extra Rinse Soft Plus
Plus Steam
Delay
Start
Time
Save
1
Programme dial
2
Spin touch button
3
Temp. touch button
4
Display
5
Delay Start touch button
6
Time Save touch button
7
Start/Pause touch button
8
Plus Steam touch button and
permanent Child Lock option
9
Soft Plus touch button
10
Extra Rinse touch button
11
Stains touch button
12
On/Off push button
13
Prewash touch button
5.2 Display
ENGLISH 17
