Page #25 background imageLoading...
Page #25 background image
Programme
Default tem-
perature
Temperature
range
Reference
spin speed
Spin speed
range
Maxi-
mum
load
Programme description
(Type of load and soil level)
20min 3kg
30 °C
40 °C - 30 °C
1200 rpm
(1200- 400
rpm)
3 kg Cotton and synthetic items lightly soiled or
once worn.
Sport
30 °C
40 °C - Cold
1200 rpm
(1200- 400
rpm)
3 kg Synthetic sportswear. Intensive short cycle to
deeply wash sportswear.
Denim
30 °C
40 °C - Cold
800 rpm
(1200 - 400
rpm)
3 kg Special programme for Denim clothing with
delicate washing phase to minimize colour
fading and marks. For better care a reduced
load size is recommended.
Wool/Silk
40 °C
40 °C - Cold
1200 rpm
(1200 - 400
rpm)
1.5 kg Machine washable wool, hand washable wool
and other fabrics with «hand washing» care
symbol
6)
.
1)
Standard programmes for the Energy Label consumption values. According to regulation
1061/2010, these programmes are respectively the «Standard 60°C cotton programme» and the «Stand-
ard 40°C cotton programme». They are the most efficient programmes in terms of combined energy and
water consumption for washing normally soiled cotton laundry.
The water temperature of the washing phase may differ from the temperature declared
for the selected programme.
2)
Washing programme.
3)
Washing programme and waterproofing phase.
4)
Steam programme doesn't remove particularly intense odour.
5)
After the steam treatment the laundry can be humid. Hang items out for a few minutes.
6)
During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
Programme options compatibility
Programme
Spin
No Spin
Prewash
1)
Stains
2)
Extra Rinse
Soft Plus
Plus Steam
Delay Start
Time Save
Cottons
ENGLISH 25

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AEG L7FC8432BI and is the answer not in the manual?

AEG L7FC8432BI Specifications

General IconGeneral
Door colorStainless steel
Door hingeLeft
Cord length1.5 m
Drum volume52 L
Control typeRotary
Loading typeFront-load
Product colorWhite
Built-in displayYes
Custom panel-readyNo
Outlet hose length0.145 m
Appliance placementFreestanding
Dispenser tray type3-way
Drum capacity8 kg
Cycle time (max)295 min
Residual moisture52 %
Spin-drying classB
Maximum spin speed1400 RPM
Noise level (spin)68 dB
Noise level (wash)46 dB
Number of washing programs-
Cycle time (quick washing program)20 min
Current13 A
Connected load2000 W
AC input voltage220 - 240 V
AC input frequency50 Hz
Energy efficiency scaleA to G
Power consumption (off)0.3 W
Water consumption per cycle47 L
Energy consumption washing per cycle0.82 kWh
Weight and Dimensions IconWeight and Dimensions
Depth554 mm
Width596 mm
Height819 mm
