2. Position it toward left or right depending on
the position of the water tap. Make sure that
the inlet hose is not in vertical position.
3. If necessary, loosen the ring nut to set it in
the correct position.
4. Connect the water inlet hose to the cold
water tap with 3/4'' thread.
CAUTION!
Make sure there is no damage to hoses
and there are no leaks from the
couplings. Do not use an extension hose
if the inlet hose is too short. Contact the
service centre for a replacement inlet
hose.
WARNING!
The inlet water shall not exceed 25 °C.
5.4 Water drainage
The drain hose should be positioned at a
height of not less than 60 cm and not more
than 100 cm from the floor.
You can extend the drain hose to
maximum 400 cm. Contact the
authorized service centre to buy the other
drain hose and the extension.
• Connect the drain hose to the spigot and
tighten it with a clamp.
• Position the hose directly to a built-in drain
pipe in the room wall and tighten it with a
clamp.
• Without the plastic hose guide, to a sink
spigot - put the drain hose in the spigot
and tighten it with a clamp.
• To a stand pipe with vent hole - insert the
drain hose directly into a drain pipe or
stand pipe.
• The drain hose can be bent into U shape
and put around the plastic guide. On the
edge of a sink - fasten the guide to the
water tap or to the wall.
Make sure that the drain hose makes a
loop to prevent particles going into the
appliance from the sink.
Make sure that the plastic guide cannot
move when the appliance drains and the
drain hose end is not immersed in the
water. There may be a return of dirty
water into the appliance. Buy accessories
from authorised supplier.
The end of the drain hose must always
be ventilated , i.e. the inner diameter of
the drain pipe (min. 38 mm - min. 1.5")
must be larger than the external diameter
of the drain hose.
ENGLISH 9
