AEG LFR6114O2B User Manual

WARNING!
It is possible to see
water flowing from the
drain hose. This is
because the washing
machine has been
tested at the factory.
4. Remove the three bolts by using the
key supplied with the appliance. Pull
out the plastic spacers.
We recommend that you
keep the packaging and
the transit bolts for any
transport of the appliance.
5. Put the plastic caps, that you find in
the user manual bag, in the holes.
5.2 Positioning and levelling
1. Install the appliance on a flat hard
floor.
Make sure that carpets do
not stop the air circulation
below the appliance.
Make sure that the appliance
does not touch the wall or
other units.
2. Loosen or tighten the feet to adjust
the level.
WARNING!
Do not put cardboard, wood
or equivalent materials
below the appliance feet to
adjust the level.
x4
The appliance must be level and stable.
A correct adjustment of the
appliance level prevents the
vibration, noise and the
movement of the appliance
when in operation.
When the appliance is
installed on a plinth or a
tumble dryer is stacked on
the washing machine, use
the accessories described in
chapter 'Accessories'. Read
carefully the instructions
supplied with the appliance
and with the accessory.
5.3 The inlet hose
1. Connect the water inlet hose to the
back of the appliance.
ENGLISH 9

AEG LFR6114O2B Specifications

General

Door type	Tempered glass
Door hinge	Left
Cord length	1.8 m
Drum volume	68.6 L
Control type	Rotary
Display type	LED
Door opening	Side opening
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Connected load	2200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	52 L
Energy consumption washing per cycle	0.512 kWh
Drum capacity	10 kg
Cycle time (max)	230 min
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	76 dB
Noise level (wash)	- dB
Number of washing programs	-
Automatic dosing system	No

Weight and Dimensions

Depth	636 mm
Width	597 mm
Height	847 mm
