AEG LFR6114O2B User Manual

4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59,7 cm /84,7 cm /66,0 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
Level of protection against ingress of solid particles and
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against mois‐
ture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
10 bar (1.0 MPa)
Water supply
1)
Cold water
Maximum Load Cotton 10 kg
Spin Speed Maximum spin speed 1351 rpm
1)
Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
1. Open the door. Remove all the items
from the drum.
Accessories delivered
with the appliance may
vary depending on the
model.
2. Put the packaging element on the
floor behind the appliance and
carefully put it down onto its rear
side. Remove the polystyrene
protection from the bottom.
1
2
CAUTION!
Do not lay washing machine
on its front.
3. Put the appliance back into an
upright position. Remove the power
supply cable and the drain hose from
the hose holders.
www.aeg.com8

AEG LFR6114O2B Specifications

General

Door type	Tempered glass
Door hinge	Left
Cord length	1.8 m
Drum volume	68.6 L
Control type	Rotary
Display type	LED
Door opening	Side opening
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Connected load	2200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	52 L
Energy consumption washing per cycle	0.512 kWh
Drum capacity	10 kg
Cycle time (max)	230 min
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	76 dB
Noise level (wash)	- dB
Number of washing programs	-
Automatic dosing system	No

Weight and Dimensions

Depth	636 mm
Width	597 mm
Height	847 mm
