8 Appliance overview
Appliance overview
Microwave oven & accessories
1. Front trim
2. Oven lamp
3. Control panel
4. Door opening button
5. Waveguide cover
6. Oven cavity
7. Seal packing
8. Door seals and sealing surfaces
9. Fixing points (4 points)
10. Ventilation openings
11. Outer cover
12. Rear cabinet
13. Power supply cord
1
7
8
10
11
13
12
9
2
3
4
65
Check to make sure the following accessories are
provided:
(1) Turntable (2) Turntable support
(3) 4 fixing screws (not shown)
• Place the turntable support in the seal
packing on the floor of the cavity.
• Then place the turntable on the turntable
support.
• To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim
when removing them from the oven.
IImmppoorrttaanntt::
When yo
u order accessories, please mention two
items: part name and model name to your dealer
or local Service Force Centre.
1
2
