AEG RCB646E3MB User Manual

EN -22-
Accessories
The Fresh Dial
If the crisper is full, the fresh dial located in front of the
crisper should be opened. This allows the air in the
crisper and the humidity rate to be controlled, to increase
the life of food within.
The dial, located behind the shelf, must be opened if any
condensation is seen on the glass shelf.
(In some models)
Fresh dial
The Freezer Box
The freezer box allows food to be accessed more easily.
Removing the freezer box:
• Pull the box out as far as possible
• Pull the front of the box up and out
Carry out the opposite of this operation when
retting the sliding compartment.
Always keep hold of the handle of the box while
removing it.
Freezer boxes
Freezer upper cover
/ Freezer box
The Icematic
• Pull the lever towards you and remove the ice maker tray
• Fill with water to the marked level
• Hold the left end of the lever and set the ice-tray on the
icebox
• When ice cubes have formed, twist the lever to drop the
ice cubes into the icebox.
Do not ll the icebox with water in order to make ice.
It will break.

AEG RCB646E3MB Specifications

General

Lamp type	LED
Fridge net capacity	344 L
Fridge interior light	Yes
Number of vegetable drawers	2
Multi-Airflow system (fridge)	-
Fridge number of shelves/baskets	4
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	9 kg/24h
Freezer net capacity	137 L
Freezer number of shelves/baskets	3
Storage time during power failure	24 h
Door hinge	Right
Display type	LCD
Product color	Black, Grey, Stainless steel
Appliance placement	Freestanding
Connected load	- W
AC input voltage	220 - 240 V
Annual energy consumption	287 kWh
Noise level	43 dB
Total net capacity	481 L
Fresh zone compartment net capacity	24 L
Cord length	2.5 m

Weight and Dimensions

Depth	712 mm
Width	700 mm
Height	1920 mm
