AEG TB5050TW - Product Description; Control Panel

3. PRODUCT DESCRIPTION
1 2
6
3
4
5
7
8
9
10
1
Water container
2
Control panel
3
Internal light
4
Appliance door
5
Filter
6
Rating plate
7
Airflow slots
8
Heat Exchanger lid
9
Heat Exchanger cover
10
Adjustable feet
For ease of loading laundry
or ease of installation the
door is reversible. (see
separate leaflet).
4. CONTROL PANEL
1
89 7 6
3
5
4
2
1
Programme knob and RESET
switch
2
Display
3
Zeit (Time Dry) touch button
4
Start/Pause touch button
5
Zeitvorwahl (Delay Start) touch
button
6
Knitterschutz (Extra Anticrease)
touch button
7
Extra Leise (Extra Silent) touch
button
8
Trockengrad (Dryness Level)
touch button
9
On/Off button
ENGLISH 7
