A= Motor head
B= Rotary switch
C= Rocker switch
D = Quick disconnect coupler
E= Hose connection
F= Dust container
G = Guide rolls
H = Suspension pin / Stop position
I= Vice action latch
J= Cable
K = Carry handle with cable cradle
L = Suction tube or telescope tube, depending on design
M = Flexible pressure tubing
N = Shut-off valve
O = Suction control
P= Clip
Q= Suction hose
R = Motor protection filter
S = Foam filter
T = Fine paper filter
U = Tension ring
V = Paper filter
W = Detergent tank
1 = Spray suction nozzle for carpet
2 = Hard flooring adapter
3 = Spray suction nozzle for upholstery
4 = Universal flooring nozzle
5 = Groove nozzle
6 = Upholstery nozzle
7 = Vacuuming brush
