AA82 InterMUSIC™ Stereo Intercom System
SM09-1 Installation and Operation Manual
April 16, 2012 Rev: 2.00 Page 2-6
ENG-FORM: 805-0100.DOTX
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
2.6 Accessories Required
Installation kit p/n AA82-001-IKC (25 pin D-min Female Crimp) is required to complete the installation.
The kit includes AEM Part No. D25SL-IKC.
AA82-001-IKC consists of:
Quantity Description AEM Part No.
1 D-min 25 Socket Housing 20-21-025
25 MS Crimp Socket 20-26-901
1* Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 25 Pin Connector Hood 20-29-026
3 5/8" 6-32 Black Pan Head Screw 25-11-427
2 Fluted 1/8" Knob 40-18-002
1 Fluted 1/8" Music Knob 40-18-MUS2
1 Hole Overlay 43-10-083
1 Rectangular Faceplate 50-04-821
* Use as required.
Installation kit p/n AA82-060-IKC (44 pin D-min Female Crimp) is required to complete the installation.
The kit includes AEM Part No. D44SL-IKC.
AA82-060-IKC consists of:
Quantity Description AEM Part No.
1 D-min 44 Socket Housing 20-20-044
44 Mini D Crimp Socket 20-26-703
1* Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 25 Pin Connector Hood 20-29-026
3 5/8" 6-32 Black Pan Head Screw 25-11-427
1 Fluted 1/8" ICS Knob 40-18-ICS2
1 Fluted 1/8" Music Knob 40-18-MUS2
1 Fluted 1/8" VOX Knob 40-18-VOX2
1 Hole Overlay 43-10-080
1 Rectangular Faceplate 50-04-821
* Use as required.
