AA82 InterMUSIC™ Stereo Intercom System
SM09-1 Installation and Operation Manual
April 16, 2012 Rev: 2.00 Page 1-3
ENG-FORM: 800-0100.DOTX
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
Inputs (AA82-060) 4 microphone ‘carbon equivalent’, 250 mVrms for full
output,
150 Ω input impedance
6 ICS keylines (active ground) for all users
2 music inputs compatible (left & right), configurable for
either portable CD/cassette, phones compatible (3 Vp-p)
or CD changer Line Out Compatible (100-500 mV @ 10
kΩ)
Inputs (all models) 1 radio input, 2.5 Vrms for full output, 1 kΩ input
impedance
bi-directional ICS Tie Line, 1 Vp-p for full output, 2 kΩ
input impedance
Outputs (AA82-001) 4 aircraft stereo headsets (300 Ω / side)
Note: Not designed for 8 Ώ headsets.
Outputs (AA82-060) 6 aircraft stereo headsets (300 Ω / side)
Note: Not designed for 8 Ω headsets
Logic ICS and RX audio both muted the music channel
No emergency or transmit functions.
1.4.2 Physical Specifications
Height 1.30” (33.0 mm)
Depth 5.60” (142.2 mm) excluding front panel controls
Width 2.60” (66.0 mm)
Weight 0.6 lbs (283.5 g) excluding external hardware
Mounting Horizontal or vertical with reversible faceplate for through-panel
mounting
1.4.3 Environmental Specifications
Temperature -40q C. to +70q C (operating)
-55˚C to +85˚C (storage)
Humidity 95% Non-condensing
Altitude 25,000 feet max
End of Section 1.0
