3. Installation of AEM

intake system.

a. When installing the intake system, do not completely tighten the hose clamps or mounting hardware until

instructed to do so.

b. Install supplied bolt and washer through fender as

shown. This picture was taken from inside the fender

well.

c. Install spacer as shown. Install the lower pipe in the

engine bay. Center the pipe in the hole in the fender

and tighten the nut on the spacer.

Mark pipe here.

And here.

e. Reinstall the washer bottle without the lower air box.

Reattach the washer fluid hose and plug in the washer

motor.

d. Mark the pipe approximately ½” above and below

the hole in the fender. Remove the pipe and apply the

adhesive neoprene material as shown. Reinstall the

intake pipe as previously directed.
