AA9x Series Single Channel Audio Controller
SM56 Installation and Operation Manual
May 22, 2012 Rev: 2.00 Page 2-7
ENG-FORM: 805-0100.DOTX
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
2.6 Accessories Required But Not Supplied
Installation kit p/n AA90-IKC (crimp) (AEM Part No. D50S37SL-IKC) is required to complete the
installation. The kit consists of one 50-Pin D-min Female Crimp Kit (D50SL-IKC) and one 37-Pin D-
min Female Crimp Kit (D37SL-IKC):
D50SL-IKC consists of
Quantity Description AEM Part No.
1 D-min 50 Socket Housing 20-21-050
50 MS Crimp Socket 20-26-901
1* Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 50 Pin Connector Hood 20-29-051
D37SL-IKC consists of
Quantity Description AEM Part No.
1 D-min 37 Socket Housing 20-21-037
37 MS Crimp Socket 20-26-901
1* Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 37 Pin Connector Hood 20-29-038
* Use as required.
2.7 Installation Drawings
Note: There are multiple versions of the AA95, AA96 and AA97. For this reason, the documents listed
below are supplied for reference only for units with Serial numbers 6000 and above. If specific
model information is required, please contact the Product Support Department at AEM.
AA95 and AA96 (All versions)
