8
Non-Contact, High Voltage Detector 275HVD
CHAPTER 3
SPECIFICATIONS
3.1 Electrical
Ranges: 240V, 2kV, 6kV, 11kV, 22kV, 33kV, 132kV, 275kV
Detection Frequency: 40 to 70Hz
Power Supply: Three 1.5V “C” cell batteries
Power Consumption: 40mA
Signal Lamp: 47 lux @ 20cm
Sound Volume: 75 db @ 1m from detector
3.2 Mechanical
Case Height: 9" (229mm)
Case Width: 3.78" (96mm)
Weight: 1.30 lbs (0.59kg) batteries included
Shock Test: IEC 68-2-29
Vibration Test: EN 61010, clause 8.3
Drop Test: EN 61010, clause 8.4
Impact Test: EN 61010, clause 8.2
3.3 Environmental
Operating Temperature: 5° to 130°F (-15° to 55°C)
Storage Temperature: -4° to 150°F (-20° to 65°C)
Humidity: 0 to 93% RH @ 104°F (40°C)
Cold Temperature: IEC 68-2-1
Dry Heat: IEC 68-2-2
Damp Heat: IEC 68-2-3
