AM450e User Manual
AEMULUS 12
7
Configuration panel:
a
Output Function
DC DVCI: Drive-Voltage Clamp-Current operation.
Continuous mode.
DC DICV: Drive-Current Clamp-Voltage operation.
Continuous mode.
b
Output Switch Enable
Turn on the selected channel if the box is checked
c
Voltage Level
Voltage level
d
V Range
Range of the voltage level
e
Current Level
Current level
f
I Range
Range of the current level
g
Bandwidth
Select either Slow, Normal or Fast setting
h
Sense
Select either Remote or Local sense connection
8
Result panel:
a
Start/Stop Button
Press “Start” to execute the configured settings.
The button will become “Stop”.
Press “Stop” to turn off the channel. The button
will appear as “Start” again automatically.
b
Temperature
Temperature readouts from the module.
MC: Master board
DC: Daughter board
c
Voltage/Current
Measured voltage and current.
Table 4: Soft Front Panel Control
Quick steps to configure the module:
1. Select PXIe address of the targeted module from the drop-down list.
2. Press “Initialize”.
3. Set desired operation. In the example above, the module is set to drive 1V and its
current compliance is set to 50mA.
4. Press “Start” to execute the commands.
5. Both voltage and current are measured.
6. Press “Stop” to turn off the channel.
7. Press “Un-Initialize” to turn off the whole module.
