2. If successful, the LED on the HEM should begin to blink slowly.
Associating your Home Energy Meter to Report Automatically.
Your Home Energy Meter can send Wattage and KWH usage reports to associated devices. To enable this, please
refer to your controller’s manual on how to configure settings on Z-Wave devices linked to your controller. Initially, the
meter is set up to report Watt and KWH reports.
Some gateways/controllers will automatically configure devices enabling you to take full advantage of the Home
Energy Meter’s features. Others may not perform any automatic configuration. In such a case you can choose to
manually configure your meter to output the data that you wish to view.
Setting automatic report flags.
Parameter 101-103 [4 byte dec] can be configured through your gateway in case that the default settings of your meter
are not what you desire.
Please refer to this link to configure your Home Energy Meter to report what you want:
https://aeotec.freshdesk.com/solution/articles/6000168073-home-energy-meter-gen5-setting-your-sensor-to-
report- (https://aeotec.freshdesk.com/solution/articles/6000168073-home-energy-meter-gen5-setting-your-sensor-to-
report-)
You may also download the configuration sheet that can be used to easily choose and automatically calculate the value
that you are looking for:
Download Excel HEM Gen5 Calculator Here (https://aeotec.freshdesk.com/helpdesk/attachments/6044361983)
-Requirements: Excel
Byte # Decimal Value Output Clamp #
byte 4 1 kWh Total Readings
byte 4 2 Watt Total Readings
byte 4 4 Voltage Total Readings
byte 4 8 Amperage Total Readings
byte 4 16 kVarh Total Readings
byte 4 32 kVar Total Readings
byte 4 64 Reserved
byte 4 128 Reserved
byte 3 256 Watt Clamp 1
byte 3 512 Watt Clamp 2
byte 3 1024 Watt Clamp 3
byte 3 2048 kWh Clamp 1
byte 3 4096 kWh Clamp 2
byte 3 8192 kWh Clamp 3
byte 3 16384 Reserved
byte 3 32768 Reserved
byte 2 65536 Voltage Clamp 1
byte 2 131072 Voltage Clamp 2
byte 2 262144 Voltage Clamp 3
byte 2 524288 Amperage Clamp 1
byte 2 1048576 Amperage Clamp 2
byte 2 2097152 Amperage Clamp 3
byte 2 4194304 Reserved
byte 2 8388608 Reserved
