INSTRUMENT AND OPERATION
•
Electric starter:
Press the start button and hold the R or L brake level to start the engine.
CAUTION:
1. The built-in side stand switch is part of the ignition circuit cut-off
system, which cuts the ignition in certain situations.
2. When press the start button, be sure to pull up the front or rear
brake level in order to connect the power supply
3. Don’t press the start button as the engine running condition.
• Head Light Switch:
1. At this position “
˙
”, the head, position and instrument light will
go out together.
2. At this position , position and instrument light will light
together.
3. At this position , head light will light.
NOTE:
The function of above is performed as engine is running.
