2.5 THROTTLE CABLE ADJUSTMENT
Slide the rubber cap of the adjuster off the
throttle housing, loosen the lock nut and adjust
the free play of the throttle lever by turning the
adjuster on the throttle housing. Inspect the free
play of the throttle lever.
2.6 AIR CLEANER MAINTENANCE
(1) Loosen the screw and remove the air
cleaner from carburetor.
(2) Disassemble the air cleaner cover and body.
(3) Remove the air cleaner element and screen..
(4) Install the new one.
(5) Assemble the air cleaner body and cover and
re-attach to the carburetor with screw.
