Park the vehicle on level ground with the front
wheels facing straight ahead.
Mark the centers of the tires to indicate the axle
center height.
Measure the distance between the marks.
Carefully move the vehicle back, let the wheels
turn 180° so the marks on the tires are aligned
with the axle center height.
Measure the distance between the marks.
Calculate the difference in the front and rear
measurements.
Toe-in: 5±10 mm
If the toe-in is out of standard, adjust it by
changing the length of the tie-rods equally by
turning the tie-rod while holding the ball joint.
Tighten the lock nuts.
Torque: 35-43 N.m
2.14 GEAR OIL MAINTENANCE
